USAXS status
HTML page refresh interval 0:05:00 (h:mm:ss)
WEB links (APS only) : Inboard above D stage Outboard above WAXS Side-sample Outboard front table up Outboard front table mid Beamline flags Inboard front table Camera server Alive list
shutters: mono: closed white: open
APS current = 200.0 mA ID E = 20.03 keV DCM E = 20.00 keV
|Q| = 5.8964e-07 1/A I = 0.0000e+00 pA/uA SAD = 228.0 mm SDD = 1073.0 mm
(mirror settings not available) Filter transmission = 1.00e+00 (Order=0.0 mm)
GC_SRM3600_5
Ready for BlackFly direct beam visualiz
spec macro: specmacro.txt time stamp: 2026-09-28 09:11:13.510835 NOT Collecting data
/share1/USAXS_data/2026-09/09_26_Ilavsky/07_10_Zhang.dat scan #1 2026-07-14T15:52:36
Linkam T96 350V/600/1500V stopped Temperature: 0.0 C Target Temp: 0C Heating rate: 0.0 C/min Pressure: 0.0 mBar No controller errors
PTC10 Heater PID: Off Temperature: 79.82 C Target Temp: 20.0 C Heating rate: 0.250 C/s

USAXS plot

plot of USAXS data

SAXS plot

plot of SAXS data

WAXS plot

plot of WAXS data

Step scan USAXS plot

plot of USAXS step scan data

USAXS plot

plot of USAXS calibrated data

SAXS plot

plot of SAXS calibrated data

WAXS plot

plot of WAXS calibrated data

Step scan USAXS plot

plot of USAXS step scan calibrated data

Tuning mr stage plot

plot of tune_mr data

Tuning ar stage plot

plot of tune_ar data

Tuning a2rp stage plot

plot of tune_a2rp data

slits

slits mm mm mm mm
HHL (r,l,t,b)
mirror (r,l,t,b)
guard (r,l,t,b) -19703.446 222.487 0.125 0.125
USAXS (h,v)(gap,center) 0.8002 0.7001 -0.9240 0.3539

detectors

detector counts VDC gain,V/A current,A
I0 1 2.58 1.00e+08 3.21e-16
I00 0 2.55 1.00e+09 0.00e+00
I000 791 1.00e+06 0.00e+00
photodiode 220628 2.53 1.00e+10 6.843e-11

motors

stage rot,deg X,mm Y,mm Z,mm
m 8.843785 -200.000 18.880
s -104.000 10.000
a 8.843827 -350.000 47.000
d -130.000 0.000
tcam 0.125
SAXS 16.140 145.000 -150.000
WAXS1 -20.000
WAXS2 -7.559
